Learn how to play .mp3 or .wav audio files stored on microSD card using an ESP32. We’ll be using the YX5300 / YX6300 Serial MP3 Music Player Module wired to an ESP32 board and programmed with Arduino IDE.
Recommended reading: [Extended Guide] ESP32 with YX5300/YX6300 MP3 Player (Arduino IDE)
Introducing the YX5300 / YX6300 Serial MP3 Music Player Module
The YX5300 / YX6300 is a low-cost Serial (UART) MP3 music player module that can be interfaced with microcontrollers (such as the ESP32, ESP8266, or Arduino) to play .mp3 or .wav files stored on a MicroSD card by sending serial commands.
Where to Buy?
You can check our Maker Advisor Tools page to compare the YX5300 / YX6300 module price in different stores:
You will also need an ESP32 development board model of your choice.
Wiring the YX5300 / YX6300 Serial MP3 Music Player to the ESP32
Wiring the MP3 player to the ESP32 is quite simple, as it only requires two serial pins: RX and TX.
| YX5300 / YX6300 | ESP32 |
| TX | GPIO 16 (UART 2 RX) |
| RX | GPIO 17 (UART 2 TX) |
| VCC | VIN (5V) |
| GND | GND |
According to the product specifications in the manual, the VCC works with voltages between 3.2V-5.2V. According to our testing, it works most reliably when connected to 5V (VIN).
* you can use any other RX/TX GPIOs. Check the ESP32 Pinout Guide:
- ESP32 Pinout Reference: Which GPIO pins should you use?
- ESP32-S3 DevKitC Pinout Reference Guide: GPIOs Explained
You may also like: ESP32 UART Communication (Serial): Set Pins, Interfaces, Send and Receive Data (Arduino IDE).
We’ll connect the RX pin to GPIO 17, and the TX pin to GPIO 16.
Important: in all projects that use serial commands, you need to connect the pins TX-RX and the RX-TX. However, if the code is not running properly (not sending/receiving serial commands), you might need to swap the wiring and connect RX-RX and TX-TX. One of our Serial MP3 players came with the wrong labels on the module, and the only way it worked was connected with TX-TX and RX-RX.
Preparing Arduino IDE
We’ll program the ESP32 board using Arduino IDE. So, make sure you have the ESP32 add-on installed. Follow the next tutorial:
If you prefer using VSCode + PlatformIO, follow the next tutorial instead:
Installing the YX5300 for ESP32 Library (YX6300 compatible)
There are several libraries to interface the YX5300 serial module with the ESP32. We’ll use the YX5300_ESP32 library by bluejunimo (even though the library is called YX5300 for ESP32, it’s also fully compatible with the YX6300 MP3 module without any additional changes).
You can install the library via the Arduino IDE library Manager. Search for YX5300 for ESP32 and install the library by bluejunimo.
Preparing the MicroSD Card
The YX5300 MP3 player has a microSD card slot where you can insert a microSD card to store your .mp3 or .wav files. Here are the main specifications that the module supports.
| YX5300 | Value |
| Supported MicroSD Cards | MicroSD <= 32GB |
| Card Format | FAT16 / FAT32 |
| Track Formats | .mp3 / .wav |
| Frequencies | 8-48 kHz |
Before proceeding with the tutorial, make sure you format your microSD card as FAT32. Follow the next instructions to format your microSD card or use a software tool like SD Card Formater (compatible with Windows and Mac OS).
1. Insert the microSD card into your computer. Go to My Computer and right-click on the SD card. Select Format as shown in the figure below.
2. A new window pops up. Select FAT32, press Start to initialize the formatting process and follow the onscreen instructions.
3. In order to play music tracks, you must have folders and your files named correctly, so the MP3 module can access them. Here’s an example of the folder and filename structure:
01/
001xxx.mp3
002xxx.mp3
003xxx.mp3
02/
004xxx.mp3
005xxx.mp3
03/
006xxx.mp3
007xxx.mp3
008xxx.mp3Your folders must have 2-digits and each tracks needs to start with 3-digit. Each track name must be unique. Note: there is a maximum of 99 folders with 255 songs in each folder.
Example, start by creating 2 folders in your microSD card (name your folders: 01 and 02):
4. Copy .mp3 or .wav files, starting with 001, 002, and 003. The file names must be sequencial and start with 3-digits.
5. Finally, remove the microSD card from you computer and attach it to the YX5300 module.
You can click here to download a .zip folder with the royalty free music files used for this project.
Connecting Headphones or Speakers to the YX5300 Module
The YX5300 doesn’t come with any headphones or speakers, but you can use some heaphones similar to the ones illustrated in the image below and plug them into the module headphone jack.
Code – Play Sound .mp3/.wav files using the YX5300 / YX6300 MP3 Player
The following code is the one provided by the library to play some with the YX5300 MP3 player module connected to an ESP32. It will play the audio files stored in the microSD card through the headphone or speaker.
/*********
Rui Santos & Sara Santos - Random Nerd Tutorials
Complete project details at https://RandomNerdTutorials.com/esp32-yx5300-yx6300-mp3-player-arduino/
Example based on the library example by bluejunimo https://github.com/bluejunimo/YX5300_ESP32/
*********/
#include <YX5300_ESP32.h>
// Connect to YX5300 Serial pins (RX and TX)
#define RX 16
#define TX 17
// mp3 object
YX5300_ESP32 mp3;
void setup() {
// Initialize connection with the YX5300/YX6300 module
mp3 = YX5300_ESP32(Serial2, RX, TX);
// Shows the hex commands being sent to the mp3 device (includes helpful errors)
Serial.begin(115200);
mp3.enableDebugging();
// Plays the first track stored on the microSD Card (Track Formats .mp3/.wav | Frequencies 8-48 kHz)
// MicroSD Card folder and file structure, example folder name 01 and file name 001xxx.mp3:
// 01/001xxx.mp3 01/002xxx.mp3 01/003xxx.mp3 02/004xxx.mp3
mp3.playTrack(1);
}
void loop() {
// put your main code here, to run repeatedly:
}
How the Code Works
Let’s break down how the code works.
Include YX5300_ESP32 library
First, you need to include the YX5300_ESP32.h library created by bluejunimo that will make it very easy to interface with the MP3 player module
#include <YX5300_ESP32.h>Initialize the YX5300
Set the YX5300 RX and TX pins and create an object for the module called mp3.
#define RX 16
#define TX 17
YX5300_ESP32 mp3;setup()
In the setup(), start by initializing the module with the a specific Serial channel.
mp3 = YX5300_ESP32(Serial2, RX, TX);Recommended reading: ESP32 UART Communication (Serial): Set Pins, Interfaces, Send and Receive Data (Arduino IDE).
Enable the Serial communication and MP3 debugging, so you can see the hex serial commands being sent to the device. With debugging enabled, you will also see helpful errors.
Serial.begin(115200);
mp3.enableDebugging();You can quickly play the first track stored on the microSD Card using the following command:
mp3.playTrack(1);Demonstration
Upload the previous code to your ESP32 board. It will play the first track stored in the microSD card. Your serial monitor should be printing a similar message:
If you have the headphones or speaker plugged into the headphone jack, you should be hearing the first track stored in your microSD card.
If you are experiencing issues with this project, follow the next troubleshooting section.
Troubleshooting the YX5300/YX6300 MP3 Player Module
If you uploaded the previous code, but you can’t hear any sound with the YX5300/YX6300 MP3 Player Module it can be one of these following issues.
- Wiring error: in all projects that use serial commands, you need to connect the pins TX-RX and the RX-TX. However, if the code is not running properly (not sending/receiving serial commands), you might need to swap the wiring and connect RX-RX and TX-TX. One of our Serial MP3 players came with the wrong labels on the module, and the only way it worked was connected with TX-TX and RX-RX;
- Not enough power: according to the product specifications in the manual, the VCC is works with voltages between 3.2V-5.2V. According to our testing, it works most reliably when connected to 5V (VIN);
- MicroSD card issue: your microSD must be equal or less than 32GB and formated with FAT16 / FAT32. The track formats must be in an .mp3 / .wav files with 8-48 kHz frequencies;
- Wrong folder structure / filenames: your microSD card folder and file structure is incorrect, example folder and filenames: 01/001xxx.mp3 01/002xxx.mp3 01/003xxx.mp3 02/004xxx.mp3;
- Issue headphones/speaker: we recommend testing your headphones/speakers in another device to make sure they are working.
Wrapping Up
This was quick guide on how to play sounds with the YX5300/YX6300 MP3 Player module with an ESP32 board. For an extended comprehensive guide on how to interface the YX5300/YX6300, you can read this other guide:
